微波感应吸顶灯

LED感应吸顶灯参数

HF:5.8GHz CW radar, ISM band                      5.8GHz高频CW雷达感应，ISM波段

Installation: indoors,ceiling mounting             安装方式:天花板或过道，走廊等

Power source: 220V/AC-240V/AC                   输入电压:220V-240V或100V-130V
                  100V/AC-130V/AC
Power frequency: 50/60Hz                             电压频率:50/60HZ
Transmission power:<0.1mw                          传输功率: <0.2mw

rated load:1200W(220V/AC-240V/AC)              额定载荷: 1200W(220V/AC-240V/AC)
              600W(100V/AC-130V/AC)                               600W(100V/AC-130V/AC)
Angle of coverage: 360° with 160°                  感应角度: 360°带160°孔径角
angle of aperture

Enclosure:IP54                                              防护等级:IP54
Reach:2-10m(radii),(adjustable)                      探测距离:直径2-10米可调
Timesetting:12sec to 30min (adjustable)          时间设定:12秒-30分钟可调
Light control:10-2000LUX                               光敏设置:10-2000LUX
Standby power:<0.9W                                   电源功耗: <0.9W

Temperature range:-10° to +50° C                 工作温度: -10° to +50° C

    Lamp part                                 灯具部分
LED quantity:324PCS                                      LED光源数量:324个
Power consumption：18W                               功耗:18W

Material :PC+Aluminum die casting                 材质:PC+压铸铝

Size:Dia230*H130mm                                   尺寸:直径320*高130mm
