AMI Series

• Single and Dual-Axis Available
• Resolution to 0.001°
• Bias Temperature Coefficient: ±0.0008°/°C
• Excellent Performance over Temperature
• Analog 0-5V, ±5V & 4-20mA Output Options
• -40° to +85°C Operating Range
• High Shock & Vibration Tolerance
• AMI datasheet (PDF)

AMV Series

• Single and Dual-Axis Available
• Resolution to 0.001°
• Bias Temperature Coefficient: ±0.0008°/°C
• Excellent Performance over Temperature
• Analog ±5V & ±10V Output Options
• -40° to +85°C Operating Range
• High Shock & Vibration Tolerance
• AMV datasheet (PDF)

AMH Series

• Single and Dual-Axis Available
• Resolution to 0.001°
• Bias Temperature Coefficient: ±0.002°/°C
• High Shock & Vibration Tolerance
• Analog 0-5V & 4-20mA Output Options
• -40° to +85°C Operating Range
• AMH datasheet (PDF)

AMS Series

• Single and Dual-Axis Available
• Resolution to 0.01°
• Bias Temperature Coefficient: ±0.006°/°C
• High Shock & Vibration Tolerance
• -40° to +85°C Temperature Range
• Analog 0-5V & 4-20mA Output Options
• Up to ±90° Full Range Output
• AMS datasheet (PDF)

AML Series

• Single and Dual-Axis Available
• Resolution to 0.05°
• Bias Temperature Coefficient: ±0.01°/°C
• High Shock & Vibration Tolerance
• -40° to +85°C Temperature Range
• Analog 0-5V & 4-20mA Output Options
• Up to ±90° Full Range Output
• AML datasheet (PDF)

DMP Series

• Single and Dual-Axis Available
• Resolution to 0.0005°
• Bias Temperature Coefficient: ±0.0008°/°C
• Minimal Thermal Drift (<0.0008°/°C Bias)
• Digital RS232, RS485 and CAN Output
• -40° to +85°C Operating Range
• DMP datasheet (PDF)

DMI Series

• Single and Dual-Axis Available
• Resolution to 0.001°
• Bias Temperature Coefficient: ±0.0008°/°C
• Excellent Performance over Temperature
• Digital RS232, RS485 and CAN Output
• -40° to +85°C Operating Range
• High Shock & Vibration Tolerance
• DMI datasheet (PDF)

DMH Series

• Single and Dual-Axis Available
• Resolution to 0.001°
• Bias Temperature Coefficient: ±0.002°/°C
• Up to ±60° Angular Range
• -40° to +85°C Temperature Range
• DMH datasheet (PDF)

DMS Series

• Single and Dual-Axis Available
• Resolution to 0.01°
• Bias Temperature Coefficient: ±0.006°/°C
• Up to ±90° Full Range Output
• -40° to +85°C Operation and Storage
•  RS232, RS485 and CAN Output
• DMS datasheet (PDF)

DML Series

• Single and Dual-Axis Available
• Resolution to 0.05°
• Bias Temperature Coefficient: ±0.008°/°C
• Up to ±90° Full Range Output
• -40° to +85°C Operation and Storage
• Digital RS232, RS485 or CAN Output
• DML datasheet (PDF)

Model 906 Little Dipper In-Place Inclinometer

Little Dipper is an in-place inclinometer system for monitoring slopes, embankments, deep excavations, tunnels, tank foundations, retaining walls and other types of ground movement. Installed as a string of vertical or horizontal sensors inside inclinometer casing, or by direct burial, this instrument provides a continuous record of ground displacement. Fiberglass rods connect the sensors inside the casing, and fins or universal pivots couple the sensors to the casing walls. Little Dipper’s on-board electronics accept a wide input voltage range and drive long cables without signal loss. The waterproof and non-corrodible ABS sensor housing also makes the Little Dipper a popular tool for underwater tilt measurements in shallow marine applications. Select analog voltage output (biaxial) or 4-20 mA output (uniaxial only).

Specifications:

• Get the most out of your tiltmeter with our installation guide

Model 904-T Clinometer Pak

The Model 904-T Clinometer Pak unites our Model 900 Biaxial Clinometer with a weatherproof NEMA 4X (IP65) enclosure for indoor or outdoor applications that demand mechanical and environmental protection. Choose the high-gain, standard or wide-angle version, each with a different angular range. Clinometer Pak’s internal circuitry accepts a wide input voltage range and provides stable, low-impedance analog outputs for measurement by dataloggers, PLC’s, digital voltmeters and other recording devices. A temperature sensor is included as a standard feature. Options include viscous damping and 0-5 Volt output. This product is also available in a submersible stainless steel enclosure.

Specifications:

• Get the most out of your tiltmeter with our installation guide

Clinometer Pak 420

The Clinometer Pak 420 is the packaged version of our Tulip 4-20 mA clinometer. Its rugged aluminum enclosure provides mechanical and environmental protection for indoor or outdoor use. This uniaxial instrument is current loop powered, so measurements can be made over long cables using an economical 2-wire pair. It also measures temperature using a built-in thermistor. Use it to monitor the angular position of conveyers, booms, ramps and machinery; perform antenna tilt error corrections; and track the pitch and roll of ships, buoys, ROV’s and towfish.

Specifications:

• Get the most out of your tiltmeter with our installation guide

Model MD 900-T Digital and Analog Clinometer

This economical biaxial clinometer has a wide variety of industrial, scientific and GPS uses. Many thousands are used today for antenna positioning, surface and subsea marine applications, structural monitoring, and industrial test and measurement. The clinometer is housed in an easily mountable enclosure and provides an RS232 serial interface and analog outputs via a 6-pin NEMA 4X connector. User-selectable firmware features include auto zero, sampling frequency, low-pass filtering and on-board data storage. Factory calibration values are stored in nonvolatile memory, and output data (X tilt, Y tilt, temperature, serial no.) are provided in several GPS-compatible formats. You can easily graph and log your measurements with our ZAGI user interface software included with every unit. Options include extended memory, real-time clock, RS422 output, viscous damping and submersible housings.

Specifications:

Model 900 Biaxial Tiltmeter

The dual-axis Model 900 is an inexpensive, gravity-referenced clinometer with analog voltage output and compact dimensions. Sold without a housing, its small size and performance make it an excellent choice for many OEM, test and measurement applications. It is available in high-gain, standard and wide-angle versions, each with a different angular range. Model 900 accepts a wide input voltage range and provides high-level single-ended outputs that are easily measured with any voltmeter or digital recording system. Viscous damping and temperature measurement are available as options.

Specifications:

Model 901 and 902 Biaxial Clinometers

Model 901 (horizontal) and 902 (vertical) Biaxial Clinometers accurately measure angular position with the same performance as Model 900, but in a slim design for use in narrow spaces. These conveniently sized, low-cost units fit neatly into underwater pressure housings, well logging tools, drilling equipment and many other devices. The dual-axis (biaxial) Models 901 and 902 measure rotations about two orthogonal axes. Their high-level voltage outputs allow signals to be delivered over long cables.

Specifications:

Tulip 4-20mA Uniaxial Clinometer

Tulip 4-20mA Uniaxial Clinometers are compact and accurate uniaxial instruments for measuring angular position where space is limited. Dimensions are the same as Models 901 and 902. High-gain, standard and wide-angle versions are available, each with a different angular range. Tulip clinometers are current loop powered, so measurements can be made over long cable lengths using an economical 2-wire pair. Choose between vertical and horizontal versions. The horizontal version measures either longitudinal or transverse rotation to give you maximum flexibility when designing it into your system. As an added bonus, Tulip clinometers measure temperature using a built-in thermistor.

Specifications:

IRIS Tilt Switch & Controller

IRIS combines a digital, dual-axis clinometer and a powerful control device in one compact unit. This remarkable instrument enables you to measure and respond to rotational movements in any direction with reference to the unchanging gravity vector. IRIS is an ideal choice for OEM applications, where it can be used to maintain platform levelness, avoid tip-over conditions, prevent out-of-range movement, and perform other control functions.

IRIS has 5 user-programmable thresholds that control TTL-compatible CMOS outputs (0-5 VDC), with 3 additional control outputs available for custom applications. Biaxial tilt and temperature are provided in user-selectable RS232 or RS422 output protocols. A powerful selection of firmware commands puts you in charge of sampling frequency, output filtering and many other functions. The versatility of this small device will amaze you!

Specifications:

Read about the
effect of cross-axis inclination on the scale factor

755-Series High-Gain Sensors, 756-Series Mid-Range Sensors

755- and 756-Series Miniature Tilt Sensors contain one or two of our electrolytic tilt transducers in a solid stainless steel or aluminum housing, with holes for vertical or horizontal mounting. These are the same high-precision sensors that we use in our 500- and 700-Series tiltmeters. Several of the models are available in vacuum-compatible versions designed for minimal outgassing under high-vacuum conditions. Two options are available, the high-gain 755-Series and mid-range 756-Series. Typical applications for these compact modules include X-ray mirrors, telescope mounts, wind tunnel models and medical devices. The sensors may be operated at a distance (cable length) up to 100m from their Jewell Instruments signal conditioner.

Specifications:

Model 84053 Mid-Range Ceramic Sensor Assembly

The Model 84053 Ceramic Sensor Assembly is made with an alumina sensor body that provides superior thermal and mechanical performance. The precision sensor has a fast warm-up, high sensitivity, high repeatability, and excellent long-term stability. It is mounted on an anodized aluminum bracket that strengthens the assembly and simplifies installation and repositioning of this versatile product. These compact sensor modules are used for leveling and positioning in a variety of test and measurement applications.

Specifications:

Model 59577 Mid-Range Ceramic Sensor

The Model 84053 Ceramic Sensor Assembly is available without the mounting bracket as our uniaxial Model 59577 Ceramic Sensor. Performance is the same.

Model 84064-02 Wide-Angle Ceramic Sensor Assembly

The Model 84064-02 Ceramic Tilt Sensor Assembly has terrific linearity over a full +/-75 degrees of angular range. The alumina sensor has a fast warm-up and excellent thermal, mechanical and long-term stability. It is mounted on an anodized aluminum bracket for strength and easy installation. The small and lightweight assembly attaches directly to the elements you want to measure, without unbalancing them or altering their performance. Use any of our analog or digital signal conditioning units for operation of these sensors.

Specifications:

Model 59579-02 Wide-Angle Ceramic Sensor

The Model 84064-02 Ceramic Sensor Assembly is available without the mounting bracket as our uniaxial Model 59579-02 Ceramic Sensor. Performance is the same.

Models 59560 (Undamped) & 59562 (Damped) Biaxial Sensors, 5-Pin

The dual-axis Model 900 is an inexpensive, gravity-referenced clinometer with analog voltage output and compact dimensions. Sold without a housing, its small size and performance make it an excellent choice for many OEM, test and measurement applications. It is available in high-gain, standard and wide-angle versions, each with a different angular range. Model 900 accepts a wide input voltage range and provides high-level single-ended outputs that are easily measured with any voltmeter or digital recording system. Viscous damping and temperature measurement are available as options.

Specifications:

Models 59580 (Undamped) & 59585 (Damped) Biaxial Sensors, 5-Pin, Wide-Angle

These 5-pin biaxial sensors are the same as Models 59560 and 59562, except they are taller, which enables them to measure angles up to 60 degrees from the vertical. Biaxial readings are obtained by using our Model 84828 or IRIS SC signal conditioners. Our other signal conditioners operate these sensors in uniaxial mode. The electrolytic fluid in sensor Model 59585 is slightly viscous to provide critical damping to remove vibrations.

Specifications:

Model 84828 Basic Signal Conditioner

The Model 84828 Basic Signal Conditioner operates one 5-pin biaxial tilt sensor or one uniaxial sensor, plus one LM-35 temperature sensor, which may be installed on the circuit board. Model 84828 has one fixed gain and one RC low-pass filter, both of which can be factory-tuned to meet your requirements. The slim, low-profile design facilitates use in the small spaces. This versatile and inexpensive signal conditioner has single-ended voltage output. The circuit is reverse polarity protected. It is an excellent choice for many of your OEM applications.

Specifications:

Model 84800 Single-Channel Signal Conditioning Card

This single-channel signal conditioning card is a compact electronic circuit that provides excitation and signal conditioning for any electrolytic tilt sensor and for one LM-35 temperature sensor. A wide input voltage range, reverse polarity protection and transient surge protection are advantages of this circuit. Its 2-pole Butterworth low-pass filter can be tuned to your special requirements. Model 84800 will drive its analog voltage output signals over cable lengths longer than 300m. Four mounting holes allow easy packaging in OEM and end-user assemblies. This circuit is an excellent match for our high-precision 755- and 756-Series sensors and for all of our other Miniature Tilt Sensors.

Specifications:

Model 83162 Dual-Channel Signal Conditioning Card

The Model 83162 Signal Conditioning Card is a precision two-channel circuit for use with all electrolytic tilt sensors. It has switchable gain and low-pass filter settings and will produce peak performance for the 755, 756, 84053 and 84064-02 Miniature Tilt Sensors. Model 83162 generates a balanced AC sensor excitation, then amplifies, rectifies and filters the sensor outputs to produce high-level DC signals proportional to the tilt angle. It includes an amplifier for an LM35 temperature sensor and will drive cable lengths over 1000m. Single-level transient surge protection is included. Distances between card and most tilt sensors can be up to 100m. Four mounting holes allow for easy packaging in OEM and end-user applications.

Specifications:

Tulip SC 4-20mA Signal Conditioning Card

Tulip SC is a 4-20mA signal conditioner for use with all of our Miniature Tilt Sensors. It operates one tilt channel and also measures temperature using a 2500 Ohm resistor. Tulip SC is current loop powered, so measurements can be made over long cable lengths using an economical 2-wire pair. You may operate this signal conditioner with normal or reverse polarity without affecting its performance. Its small size, easy setup and fast response time make Tulip SC a great choice for OEM applications that requires long cable runs or interfacing with control systems.

Specifications:

IRIS SC Digital Signal Conditioning Card

IRIS SC provides signal conditioning and serial data output for all of our Miniature Tilt Sensors. Use it with up to two uniaxial sensors, or any biaxial sensor. It has a 16-bit A/D converter, 540K of onboard FLASH memory, a real-time clock, and it also measures temperature. Its powerful firmware commands include low-pass filtering, autozero, sampling frequency selection, RS232 or RS422 output selection, and onboard data storage. Other commands enable you to select among data formats, including formats compatible with popular GPS receivers. IRIS SC also operates as a tilt switch and controller. This product is a perfect choice for applications that require digital data streams or onboard recording of tilt measurements.

Specifications:

Model 781 Signal Conditioning Unit (Bench Top)

Model 781 is a precision, 2-channel signal conditioning unit for all electrolytic tilt sensors. It provides peak performance from your 755, 756, 84053 and 84064-02 Miniature Tilt Sensors. To build Model 781, we package an 83162 signal conditioning card in a rugged aluminum case with screw terminals on the rear panel for sensor connections, power input, and signal output. Three switches on the front panel control gain and low-pass filter settings, and power on-off.

Model 781 generates a balanced AC sensor excitation, then amplifies, rectifies and filters the sensor outputs to produce high-level DC signals proportional to the tilt angle. It also operates a LM35 temperature sensor and will drive tilt and temperature signals over 1000m cable lengths. This signal conditioner is excellent for laboratory and factory applications that require remote operation of one or two tilt sensors.

Specifications:

• Get the most out of
  your tiltmeter with our installation guide

Model 701-2 Platform Tiltmeter

The biaxial Model 701-2 Platform Tiltmeter is our most popular design for rapid installation and high precision. Using its built-in Invar leveling legs, it can be set up and operating on any hard horizontal surface within minutes. The two orthogonal tilt sensors parallel the sides of the base plate. Each tiltmeter includes a temperature sensor. The internal electronics drive signals over cable lengths greater than 1000m. Model 701-2 has two switchable gains and two low-pass filter settings. This tiltmeter is a popular choice for volcano monitoring, platform leveling, and measuring structural response to applied loads.

Specifications:

• Get the most out of
  your tiltmeter with our installation guide

Model 701-2(4X) Weatherproof Platform Tiltmeter

The biaxial Model 701-2(4X) Platform Tiltmeter delivers high precision and the same ease of installation as Model 701-2, but in a weatherproof housing. With its adjustable Invar legs, you can install and level the unit within minutes. It has fixed gain and filter settings. Typical applications include volcano monitoring, antenna and platform leveling, structural testing and other demanding applications in wet environments.

Specifications:

• Get the most out of
  your tiltmeter with our installation guide

Model D701 Digital Platform Tiltmeter

Model D701 Digital Platform Tiltmeter is the digital version of our Model 701-2 Platform Tiltmeter. The Invar leveling legs make it a great choice for rapid installation. The NEMA 4X enclosure provides excellent protection from moisture and wet weather. This precision instrument has a 16-bit A/D converter, low-noise electronics and two orthogonal electrolytic tilt sensors. It comes with a real-time clock, 540K of FLASH memory for on-board data storage, and our ZAGI user-interface software. User-selectable firmware commands include auto zero, sampling frequency, low-pass filtering and serial data protocol (RS232 or RS422). Output data format (X tilt, Y tilt, temperature, serial no.) is also user-selectable. Several GPS-compatible formats are provided. Ask us about wireless connectivity for these devices.

Specifications:

• Get the most out of
  your tiltmeter with our installation guide

Models 711-2 and 716-2 Floor & Wall Mount Tiltmeters

Model 711-2 and 716-2 Floor Mount and Wall Mount Tiltmeters bolt or clamp to any surface and are well suited for areas of heavy traffic or vibration. They are identical to our popular Model 701-2 Platform Tiltmeter, but have 0.5-inch (12.7 mm) diameter holes in their three corners instead of adjustable legs. The holes fit over threaded stainless steel studs, provided with each order. Both models have two switchable gains, two low-pass filter settings, and include a temperature sensor. They will drive cables longer than 1000 meters.

These precision tiltmeters are widely used for structural monitoring, load testing, and precision alignment of antennae and machinery.

Specifications:

• Get the most out of
  your tiltmeter with our installation guide

Model 711-2(4X) Weatherproof Floor Mount Tiltmeter

Model 711-2(X) with fixed gain and filter is a weatherproof version of our popular Model 711- 2 Floor Mount Tiltmeter. This precision instrument bolts or clamps to any surface and can be used in areas of heavy traffic or vibration. The tiltmeter also measures temperature, and the internal electronics will drive tilt and temperature signals over cable lengths greater than 1000m. Applications include volcano monitoring; precise alignment of telescopes and antennae, structural monitoring; and other jobs that require precision measurements under harsh operating conditions.

Specifications:

D711 Digital Datasheet

Compare Tiltmeters

• Get the most out of your tiltmeter with our installation guide

Model D711 Digital Floor Mount Tiltmeter

Model D711 Digital Floor Mount Tiltmeter is a precision digital instrument packaged in a weatherproof housing. It delivers the same performance and user-selectable firmware features as Model D701, but has 0.5 inch (12.7 mm) diameter holes in their three corners instead of adjustable legs. The holes fit over threaded stainless steel studs, provided with each order. RS232 and RS422 outputs are both included as standard features. The RS422 output will drive cables longer than 1000m. Typical applications include alignment of antennae and airframes; structural testing and monitoring; and other jobs that call for top performance under demanding operating conditions.

Specifications:

• Get the most out of your tiltmeter with our installation guide

Model 801 Tuff Tilt

Tuff Tilt is a precise and rugged uniaxial tiltmeter suitable for many different applications. This workhorse is widely used for structural monitoring and for industrial test and measurement. Housed in a rugged weatherproof/waterproof enclosure, this analog output tiltmeter may be installed outdoors and in other wet environments. Typical applications include construction monitoring, monitoring of bridges and other large structures, antenna leveling, and rotary position sensing for dam gates and other machinery. Tuff Tilt tiltmeters incorporate a ceramic tilt sensor that delivers low thermal sensitivity, high long-term stability and the best resolution of any sensor in its class. Model 801 includes a temperature sensor.

Specifications:

• Get the most out of your tiltmeter with our installation guide

Tuff Tilt 420

Tuff Tilt 420 delivers the great performance of Model 801 in a tiltmeter with 4-20 mA output. It combines precision, long-term stability and rugged durability in a compact and reliable instrument. It is current loop powered, so tilt measurements can be made over long cables using an economical 2-wire pair. Its 4-20 mA output is great for long cable runs, and it includes a thermistor for correlating tilt changes with thermally induced structural movement. Use Tuff Tilt 420 in the same places you would use Model 801, but in projects where 4-20 mA output is required.

Specifications:

• Get the most out of your tiltmeter with our installation guide

Tuff Tilt Digital

This product is the digital member of our Tuff Tilt family. Use it for test and measurement work requiring serial data communications, high precision, compact size, and robustness. Among its standard features are 16-bit A/D resolution, onboard data logging, a real-time clock, and measurement of temperature. User-selectable firmware commands include autozero, sampling frequency, low-pass filtering, and output data format. Several output formats are supported, including those compatible with popular GPS receivers. You can combine the Tuff Tilt Digital with GPS for simultaneous measurement of displacement and tilt. We also offer wireless connectivity and tilt alarm capability for these devices. ZAGI graphical user-interface software is provided with each tiltmeter.

Specifications:

• Get the most out of your tiltmeter with our installation guide

Model 802 DeepWater Submersible Tiltmeter

The Model 802 DeepWater is the fully submersible cousin of our Model 801 Tuff Tilt. Performance features are the same, but the DeepWater housing is machined from a solid piece of 316 stainless steel and incorporates a high-pressure neoprene connector. Pressure rating is 250 bars (2500 meters depth). Higher-pressure versions may be special ordered. Temperature rating is governed by the neoprene connector. Wider temperature range is available with other connector types. DeepWater tiltmeters are excellent choices for monitoring dams, oil platforms, pipelines and underwater machinery.

Specifications:

DeepWater 420 Datasheet

• Get the most out of your tiltmeter with our installation guide

DeepWater 420

DeepWater 420 is the submersible equivalent of our Tuff Tilt 420. It has 4-20 mA output and is current loop powered, so that tilt measurements can be made using a 2-wire pair. The massive housing is machined from a solid piece of 316 stainless steel and is rated to 250 bars pressure (2500 meters depth). Higher-pressure versions may be special ordered. The temperature rating is governed by the neoprene connector. Wider temperature range is available with other connector types. Use DeepWater 420 in the same places you would use Model 802, but where 4-20 mA output is required.

Specifications:

• Get the most out of your tiltmeter with our installation guide

DeepWater Digital

DeepWater Digital is the submersible version of our Tuff Tilt Digital tiltmeter. Performance and firmware are the same, but the 316 stainless steel housing is rated for submergence to 250 bars pressure (2500 meters depth). The neoprene connector is wet-mateable. DeepWater tiltmeters are excellent choices for offshore work and other underwater applications.

Specifications:

Model 800P Portable Tiltmeter

The Model 800P Portable Tiltmeter is a versatile and accurate hand-held instrument for monitoring structural and foundation movement. Measurements are taken from tilt plates that have been cemented or bolted to any horizontal or vertical surface. Indexing bars on the bottom and sides of the tiltmeter enable you to reposition it on the tilt plate exactly, every time. Surveys are economical because only one tiltmeter is needed to make measurements at an unlimited number of points. When continuous monitoring is not required, Model 800P is an excellent choice. The Portable Tiltmeter System includes one tiltmeter, one power and display unit, and a tough plastic carrying case. Ceramic or Aluminum Tilt plates are purchased separately.

Specifications:

• Operational Temp -55° C to +180° C
• QFM-180 Datasheet
• Round Outline Drawing
• Square Outline Drawing

• High Temperature Range
• Excellent Repeatability
• High Accuracy
• Environmentally Rugged
• High Stability
• Square  Mounting Flanges
• Miniature Compact Design
• Built In Self-Test System

• Borehole Mapping
• Measure While Drilling (MWD)
• Structural Monitoring
• Oil Drilling
• Survey Applications
• Orientation Systems for Drilling Applications
• Automotive Test
• Platform Monitoring
• Robotics

• Operational Temp -55° C to +180° C
• QFA-180 Datasheet
• Round Outline Drawing
• Square Outline Drawing

• High Temperature Range
• Excellent Repeatability
• High Accuracy
• Environmentally Rugged
• High Stability
• Choice of Square or Round Mounting Flanges
• Small Compact Design
• Built In Self-Test System

• Well Borehole Logging (Wireline)
• Measure While Drilling (MWD)
• Structural Monitoring
• Oil Drilling
• Survey Applications
• Orientation Systems for Drilling Applications

• Operational Temp -55° C to +150° C
• QFA-150 Datasheet

• Mid Range Temperature
• Excellent Repeatability
• High Accuracy
• Environmentally Rugged
• High Stability
• Choice of Square or Round Mounting Flanges
• Small Compact Design
• Built In Self-Test System

• Rail Maintenance Track Geometry
• Wind Tunnel Testing
• 3D Modeling Equipment for Large Scale Geometries
• Marine Instrumentation
• Survey Applications
• Borehole Mapping

• Operational Temp -55° C to +125° C
• QFA-125 Datasheet
• Round Outline Drawing
• Square Outline Drawing

• Mid Temperature Range
• Excellent Repeatability
• High Accuracy
• Environmentally Rugged
• High Stability
• Choice of Square or Round Mounting Flanges
• Small Compact Design
• Built In Self-Test System

• Rail Maintenance Track Geometry
• Wind Tunnel Testing
• 3D Modeling Equipment for Large Scale Geometries
• Navigation Grade Performance
• Survey Applications
• Control Systems
• Marine Instrumentation

Analog MEMS Accelerometer
AMA Series

• 1.85″ x 1.85″ x 1.89″ size
• Single, Dual and Triaxial Configuration
• Excellent long term stability
• Ruggedized for harsh environment operation
• High Sensitivity
• AMA datasheet (PDF)

Digital MEMS Accelerometer
DMA Series

• 1.85″ x 1.85″ x 1.89″ size
• Single, Dual and Triaxial Configuration
• Excellent long term stability
• Ruggedized for harsh environment operation
• High Sensitivity
• DMA datasheet (PDF)

Dynamic Concrete Strain Gage

This Dynamic Concrete Strain Gage (CSG) is a concrete embeddable strain gage designed for use in high frequency (dynamic) environments. These rugged, gages are ideal for infrastructure, and structural health monitoring applications with high levels of environmental noise. Our Dynamic CSGs use a Wheatstone bridge circuit, which compensates for temperature and lead resistance, and filter unwanted noise for precision strain measurements. Units are offered in either bending strain or axial strain configurations (please specify per order), and are easily implemented into conventional data acquisition systems. Jewell’s Dynamic CSGs are a perfect choice for measuring strains in pavement, columns, bridge components and other concrete structural components.

Specifications:

Dynamic Asphalt Strain Gage

Jewell Instruments offers a Dynamic Asphalt Strain Gage (ASG), an embeddable strain gage designed for use in high frequency (dynamic) environments. These rugged gages are built to withstand high temperatures and vibratory roller compaction, making them ideal for infrastructure and construction type projects. Our ASGs utilize a Wheatstone bridge circuit, which compensates for temperature and lead resistance, and filter unwanted noise for precision strain measurements. Units are offered in either bending strain or axial strain configurations (please specify per order). Our Dynamic ASGs are a perfect choice for measuring strains in asphalt pavement and for comprehensive infrastructure monitoring.

Specifications:
